Piezoelectric strain sensor 9237B20

screw-infor dynamic applications

• Nominal sensitivity: –34 pC/με • Dimensions LxBxH (mm): 62.25x25x26.7 • Output connection: KIAG 10-32 neg. with M13x1 adapter Measuring range [µε] -800 … 800 με Calibrations Calibrated measuring range [με] 0 … 500 με Product type Strain sensor type Surface strain sensor Mechanical properties Mechanical overload ±1000 με Metrological characteristics Linearity ≤±2 %FSO Nominal sensitivity [pC/με] -34 pC/με Electrical properties Output signal type Charge (Piezoelectric, PE)
