Rotary switch MER seriesmultipoleelectromechanical
Add to favorites
Compare this product
Characteristics
- Type
- rotary
- Number of poles
- multipole
- Other characteristics
- electromechanical
- Primary current
0.5 mA, 1 mA, 10 mA
- Voltage
5 V, 100 V, 300 V
Description
rating:5 V DC. 1 mA
Insulation resistance:>100 MQ
Dielectric strength:300 V. 50 Hz for the duration of 1 minute
Operating temperature:-40 °C to +85 °C
Rotational/Detent torque:0.5/1 .ONcm
Pulses/Detents per turn:15/30
Mechanical life:>15000 cycles
Pushbutton (optional):actuation force 5 N. travel 0.5 mm. life >10000 operations
Contacts:silver-plated
Terminals:silver-plated
Mounting:on pc-board
single hole mounting M 7 x 0.75
Soldering conditions:wave-soldering - max.: 5 sec. 260 °C
