8 10/100/1000T + 2 1000M SFP L2+ Industrial Managed Switch w/ Enhanced G.8032 Ring
SFP cage support 1G Mbps SFP
Enhanced G.8032 ring protection < 20ms for single ring. Supports enhanced mode and basic mode; Enhanced G.8032 ring covers multicast packets; MSTP 8/16**MSTI /RSTP ; support MRP ring**
Miss-wiring avoidance & node failure protection
User friendly UI, including auto topology drawing and DDM threshold monitoring with dB values***; Complete CLI
Support LACP link aggregation, IGMP v3/router port, DHCP server & DHCP Option82; DHCP Snooping; Port based DHCP distribution, Mac based DHCP server, QoS by VLAN**, SSH v2/SSL, HTTPS, INGRESS ACL L2/L3,TACACS+**, QinQ**, SMS**
Protocol based VLAN** ; IPv4/IPv6 Subnet based VLAN**
Optional Environmental Monitoring** for temp., voltage and current
USB port for backup, restore the configuration file
Wide range operation temperature (-E model):-40~75C/-40~167F
Lantech IGS-3208GSFP is a high performance L2+ all Gigabit switch with 8 10/100/1000T + 2x 1G multi-Giga- rate SFP which provides L2 wire speed and advanced security function for network aggregation deployment. It delivers ITU G.8032 enhanced ring recovery less than 20ms for single ring, comprehensive QoS, VLAN, GVRP, advanced security SSH v2/SSL, INGRESS ACL L2/L3, IGMPv1/v2/v3/router port, DHCP server/relay, jumbo frame which are important features required in mid and large network. It also supports Cisco Discovery Protocol (CDP) and LLDP for Ciscoworks to detect the switch info and to be shown on L2 map topology.
