FEATURES
BUCKET CAPACITY
1.8 yards
PERFORMANCE
Capacity: up to 1,800 metric tons/hour
Casting distance: up to 46 m (150 ft.)
DIMENSIONS
Length from attach plate to front: 1.75 m (69 in.)
Width overall: 2.6 m (102 in.)
Height overall: 3.28 m (129 in.)
Working height: 1.32 m (52 in.)
Weight: 2,722 kg (6,000 lbs.)
ENGINE
Power: 129 kW (173 HP)
Cummins F3.8 Turbo diesel
IMPELLER
Easy to replace blades
Heavy duty spoke type
Impeller casing made of steel (highly abrasive resistant)
Hydraulic impeller casing rotation
CONVEYOR
2 heavy duty serrated augers of 431 mm (17 in.)
LOADING CHUTE
Hydraulic control
Horizontal rotation angle: 300°
Casting distance: 1.2 m (4 ft.) to 15 m (50 ft.)
OPTIONS
Female quick attach system
Hydraulic steering vanes
Impeller casing having a 140° adjustable cast angle: Flat from the right to 40° to the left.
Carbide chromium drum
Carbide chromium chute
Hydraulic tilting chute
Heavy duty rubber scraper
Replaceable conveyor ice cutting teeth
Working lights on bucket and loading chute
Battery charger
Battery heater
Trumpet horn
Telescopic loading chute of 457 mm (18 in.)
Wireless controls
DEL working lights on bucket and loading chute
