FEATURES
BUCKET CAPACITY
3 yards
PERFORMANCE
Capacity: up to 3,000 metric tons / hour
Throwing distance: up to 46 m (150 ft.)
DIMENSIONS
Length from hitch plate 2.2 m (87 in.)
Overall width: 2.80 to 2.90 m (110-114 in.)
Overall weight: 3.53 to 3.99 m (139-157 in.)
Working height: 1.52 m (60 in.)
Weight: 4,944 kg (10,900 lbs.)
ENGINE
Power: 231-272 kW (310-365 HP)
Engine Cummins QSB6.7 Tier 4F - Cummins L9 Tier 4F
IMPELLER
5 blades - easy to replace
Impeller casting: 140° total cast angle: from 40° left, horizontal to right from the ground
Diameter: 1.02 m (40 in.)
CONVEYOR
2 augers each 660 mm (26 in.) (serrated)
LOADING CHUTE
Hydraulically controlled
Horizontal rotation angle: 300º
Throwing distance: 1.2 to 15 m (4-50 ft.)
OPTIONS
Female quick coupler
Hydraulic steering vanes
Hydraulic tilting chute
Battery charger
Conveyor with icebreaker
Chromium carbide impeller casing
Chromium carbide chute
Tungsten carbide blades
Heavy-duty rubber blade
Replaceable icebreaker teeth for conveyor
Work light on bucket and loading chute
Telescopic chute: 457 mm (18 in.)
Trumpet horn
Wireless remote control
