FEATURES
BUCKET CAPACITY
5 yards
PERFORMANCE
Capacity: up to 7,000 metric tons / hour
Throwing distance: up to 55 m (180 ft.)
DIMENSION
Approximate length from hitch plate: 3.4 m (134 in.)
Overall width: 3 m (120 in.)
Overall height:
Working height: 1.9 m (75 in.)
Weight: 10,000 kg (22,000 lbs.)
ENGINE
Power: 597 kW (800 HP)
Filtration with pre-filter
Caterpillar C18 Tier 4F
IMPELLER
Impeller casting: 90° total cast angle: Vertical to left, horizontal to right from the ground
Diameter: 1.8 m (70 in.)
Number of blades: 6
IMPELLER CASING
One piece shotgun-type with output resistant to abrasion of up to 500 Brinell Hardness
OPTIONS
Female quick coupler
Right hydraulic side rudder
Residential-type muffler
