FEATURES
BUCKET CAPACITY
7 yards
PERFORMANCE
Capacity: up to 8,500 metric tons / hour
Throwing distance: up to 55 m (180 ft.)
DIMENSION
Approximate length from hitch plate: 4.45 m (175 in)
Overall width: 3.53 m (139 in)
Overall height: 2.9 m (114 in)
Working height: 1.9 m (75 in)
Weight: 11,000 kg (24,200 lb)
ENGINE
Power: 783 kW (1050 HP)
Filtration with pre-filter
Caterpillar C27 Tier 4F
IMPELLER
Impeller casting: 95° total cast angle: Vertical to left, horizontal to right from the ground
Diameter: 1.8 m (70 in)
Number of blades: 5
IMPELLER CASING
One piece shotgun-type with output resistant to abrasion of up to 500 Brinell Hardness
OPTIONS
Female quick coupler
Right hydraulic side rudder
After-treatment with an Selective Catalytic Reduction System
Wired or wireless controls
3 LED bar work lights
Height adjustable ski kit
