Industrial tent

for event organizationevent

Overview
The Thermo Roof Cube Double Decker is a double-deck event tent designed to double usable area within a single projected footprint. Available clear spans: 10 m, 15 m, 20 m, 25 m, 30 m and 40 m. Main profile section: 300x120x5 mm (4-channel). The roof uses thermally insulated PVC fabric to provide heat insulation and thermostatic performance, and the roof has a 7° pitch for a flat, permanent-building appearance. A parapet at the eave increases area for banner advertising.

Key features

• Clear span options: 10, 15, 20, 25, 30, 40 m
• Main profile: 300x120x5 mm (4-channel)
• Thermally insulated PVC roof membrane (insulation, heat preservation, thermostatic effect)
• Flat appearance with 7° roof pitch; parapet on eave for banners
• Second deck doubles usable event area within same footprint; optional outdoor balcony
• Designed for VIP stands and temporary industrial/event uses

Options & accessories

• Lighting systems, water drainage, lightning protection
• Aluminum stairs (internal or external)
• Sidewalls with clear PVC church windows
• Ground anchors, interior lining and curtains
• Glass wall systems, ABS hard walls, sandwich panel walls, steel-sheet walls
• Glass doors, sliding doors, electromotor rolling doors
• Transparent roof covers and sidewalls, flooring systems

Patents
Patent numbers: ZL201520433483.4; ZL201120397706.8; ZL201520503051.6; ZL201520503410.8; ZL201520411133.8

Stairs types

• A1
• A2
• B
• C1
• C2
• D
• E1
• E2

Technical specifications
Span Width | Eave Height | Ridge Height | Bay Distance | Main Profile
10 m | 8 m | 8.54 m | 5 m | 300x120x5 mm (4-channel)
15 m | 8 m | 8.89 m | 5 m | 300x120x5 mm (4-channel)
20 m | 8 m | 9.2 m | 5 m | 300x120x5 mm (4-channel)
25 m | 8 m | 9.5 m | 5 m | 300x120x5 mm (4-channel)
30 m | 8 m | 9.8 m | 5 m | 300x120x5 mm (4-channel)
40 m | 8 m | 10 m | 5 m | 300x120x5 mm (4-channel)

Applications

• Sports event VIP stands (football, golf, equestrian, auto racing)
• Trade shows, exhibitions, corporate events
• Temporary industrial shelters and large-scale event structures
