E-Paper display IEPA-1330-RKC3-WGLD

monochromehigh-resolution13.3"

Introduction
The IEPA-1330 is a dual 13.3-inch e-paper display engineered for outdoor digital signage and information panels. It features an aluminium enclosure with toughened front glass, meeting IK10 impact resistance and IP65 ingress protection. Designed for pole or fixed-surface mounting, the unit supports wireless connectivity and battery-powered operation. Optional modules include front illumination, NFC and interactive functions for flexible deployment.

Main features

• Dual 13.3-inch e-paper display
• High resolution 3200 x 1200
• 16-level grayscale (monochrome)
• Ultra-low power consumption; battery operation
• IK10 impact resistance
• IP65-rated for outdoor use with toughened front glass

Specification
Model Name : IEPA-1330-RKC3-WGLD
Description : Double 13.3-inch BUS E-Paper Display Solution
Size : 13.3-inch
Color : Greyscale (16 Level)
Refresh Time : 450 ms
I/O Interface : USB x 1; Power x 1
Dimensions (mm) : 242 x 750 x 56
Weight (Net) : 7 kg
Operating Temperature : -15 °C ~ 65 °C

Technical specifications

• Model Name: IEPA-1330-RKC3-WGLD
• Display: Dual 13.3-inch e-paper
• Resolution: 3200 x 1200
• Colour/Greyscale: 16-level grayscale (monochrome)
• Refresh Time: 450 ms
• Power & Connectivity: Ultra-low power operation; wireless connectivity; battery operation; I/O: USB x 1; Power x 1
• Mechanical: Dimensions 242 x 750 x 56 mm; Net weight 7 kg; Aluminium enclosure with toughened front glass
• Environmental & Protection: IK10 impact resistance; IP65 rated for outdoor use; Operating temperature -15 °C to 65 °C
• Optional: Front illumination, NFC, interactive functions
