TFT LCD panel PC IPPS-3323-RKC3

LED backlightsunlight-readableRockchip RK3568

Overview The IPPS-3323 is a 33.2-inch color TFT-LCD display with a 1:1 square aspect ratio and 1920 x 1920 resolution. Part of Litemax’s Squarepixel series, it features a high-brightness, power-efficient LED backlight and provides sunlight-readable performance for digital signage, public transportation, exhibition halls, department stores and vending machines.

Main features

• High Brightness 500 cd/m2
• Aspect ratio 1:1 (Squarepixel series)
• Quad-core ARM Cortex-A55 CPU (Rockchip RK3568) and Mali-G52 GPU
• 2GB RAM, 16GB eMMC storage
• Backlight MTBF: 50,000 hours
• Low power efficient LED backlight

Technical specifications (table) Model Name : IPPS-3323-RKC3
Display Area (mm) : 596.16(H) x 596.16(V)
Resolution : 1920 x 1920
Brightness : 500 cd/m2
Pixel Pitch (H/V) : 0.3105(H) x 0.3105(V)
Contrast Ratio : 1000 : 1
Viewing Angle (H/V) : 178°(H), 178°(V)
Backlight MTBF (typ.) : 50,000 hours
CPU : Rockchip RK3568 Quad-core ARM Cortex-A55 CPU
System I/O : DP in x1, USB2.0(type A) x2, USB2.0(type C) x1
Audio : 3.5 mm audio jack
HDD / Storage : 16GB eMMC
LCD Power Consumption : 75W
Operating Temperature : 0 ˚C ~ 50 ˚C
Storage Temperature : -20 ˚C ~ 60 ˚C
Dimensions (W x D x H) mm : 615.8 x 615.8 x 54.5
Weight : 13.5 kg
Mounting : 400x200, 400x300

Key specifications

• Display size: 33.2" TFT-LCD, square 1:1 aspect ratio
• Resolution: 1920 x 1920
• Brightness: 500 cd/m2
• CPU: Rockchip RK3568 (Quad-core ARM Cortex-A55)
• Memory: 2GB RAM
• Storage: 16GB eMMC
• Power consumption (LCD): 75W
• Operating temperature: 0–50°C; Storage temperature: -20–60°C
• Mechanical: 615.8 x 615.8 x 54.5 mm; Weight 13.5 kg
• Mounting options: 400x200, 400x300
