Double-scissor lift table

simple scissortriple-scissorhydraulic

Description
Hydraulic lifting tables are designed to facilitate loading in all types of facilities, including logistics centers, laboratories, distribution and food-processing plants. Manufactured to order, they bridge the vertical differences required for the movement of goods. Our engineering office studies each case and proposes a solution so that different loads and lift heights can be handled in an agile and practical way. With a base made of anti-slip tread plate, they allow level changes to be negotiated for both indoor and outdoor areas of the building. Designed to withstand traffic with the required load, they form a vertical logistics solution while meeting the appropriate safety requirements for each sector.

Optional equipment

• Different table types: single, double or multiple
• Lifting travel from 800 to 1600 mm (depending on model)
• Lower frame allowing anchoring to the floor
• Finish options: hot-dip galvanized or stainless steel
• Retractable lip or hinged lip options
• Different load capacities (depending on model)

Frequently asked questions

• When is installation recommended?: They are recommended in work areas with two different floor levels, as a solution when it is not possible to create a pit for a loading ramp; they are useful for positioning in production processes, overcoming architectural barriers or improving ergonomics.
• What information is required to request a quote?: Type of load to be lifted, required lifting height and maximum load weight. For lifts over three meters, a goods lift is recommended instead of an industrial lifting table.
• What models are available?: Single model (positioning/transfer between levels), double model (handling loads up to 5,000 kg), multiple model (greater lift), special models (large-dimension loads) and extra-flat model (flush-to-floor installation).

Characteristics / Technical specifications

• Maximum load: up to 10,000 kg
• Manufacturing length: possible up to 5 metres
• Lifting travel: 0.60 times its length (depending on design)
• Materials and finishes: manufactured in stainless steel, hot-dip galvanized, painted or combinations of these finishes
• Surface: smooth plate or anti-slip tread plate
• Available travels (depending on model): 800 to 1600 mm
