Ethernet video player BPC5023A

HDMIdigitalDigital signage

Overview
The BPC5023A is a compact, fanless digital signage player designed for reliable 24/7 operation in retail, transportation, corporate and public spaces. Powered by an Intel® Amston Lake Atom® x7433RE quad‑core processor, it delivers smooth dual independent 4K@60Hz playback, TPM 2.0 hardware security and flexible storage/memory options for managed signage deployments.

Key Features

• Fanless, solid‑state design for unattended 24/7 operation
• Intel® Amston Lake Atom® x7433RE Quad‑Core CPU (up to 3.40 GHz)
• Dual HDMI 2.0b outputs supporting independent displays at up to 3840 x 2160 @ 60Hz
• EDID emulation and HDMI‑CEC support for stable display behavior
• Peripheral Device Power Control (PDPC) for USB peripheral management
• Wake on LAN (WoL) for remote power control
• TPM 2.0 hardware security (Hardware Root of Trust)
• Optional M.2 2230 Wi‑Fi/Bluetooth 5.2 expansion kit
• Compatible with standard signage CMS and cloud platforms (browser or OS‑based)

Highlights

• Intel® Amston Lake Atom® x7433RE processor
• Intelligent energy saving features, CEC and EDID emulation
• Wake on LAN and PDPC for remote management and recovery
• High‑resolution multi‑display output (dual 4K)
• cULus listing and optional Wi‑Fi/Bluetooth expansion

Front I/O and Interfaces

• 2 x HDMI 2.0b outputs (max. 3840 x 2160 @ 60Hz)
• 1 x Gigabit Ethernet (RJ‑45)
• 1 x RS‑232 (RJ‑45) COM1
• 1 x 3.5 mm line‑out audio
• 2 x USB 3.2 Type‑A, 1 x USB 2.0 Type‑A
• Momentary power pushbutton
• 2x wireless antenna ports (covered unless Wi‑Fi kit installed)

Storage & Memory

• 1 x M.2 2280 SSD: 64 GB (M.2 SATA3 3D TLC) or NVMe 3D TLC for higher capacities
• SSD options: 64 GB / 128 GB / 256 GB / 512 GB / 1 TB / 2 TB
• Memory: 1 x DDR5 SO‑DIMM (8 GB or 16 GB options)

Power & Electrical

• Input power: 50 W
• Input voltage: 12 VDC ±10%
• Input current: 4.17 A max
• 50 W AC/DC power adaptor with locking DC plug included (adaptor affects operating temperature range)

Mechanical

• Dimensions (W x H x D): 8.54" x 0.88" x 4.84" (217 x 22.5 x 123 mm)
• Weight: Approx. 2.2 lbs (1.0 kg)
• Construction: Aluminum heatsink with SGCC chassis
• Mounting: Wall mount kit included

Environmental

• Operating temperature (without included adapter): -40° to 158°F (-40° to 70°C)
• Operating temperature (with included adapter): 32° to 113°F (0° to 45°C)
• Storage temperature: -40° to 185°F (-40° to 85°C)
• Storage humidity: 10%–90% non‑condensing

Security & Management

• TPM 2.0 (Hardware Root of Trust)
• Watchdog timer (256 segments) for automatic recovery
• Wake on LAN (WoL) support
• Energy saving features for scheduled power management and reduced runtime

Certifications & Ratings

• IP rating: IP30
• CE: Yes
• UL: Yes (cULus listed)
• RoHS: Yes
• FCC: Class B

What's Included

• BPC5023A series unit (configured per order)
• Wall mounting kit
• 12 VDC, 50 W power adaptor (locking DC plug)
• Warranty statement insert

FAQs (selected)

• Are these players fanless? — Yes. Fanless, solid‑state design with no moving parts for dust/vibration tolerant 24/7 operation.
• What is EDID emulation? — EDID emulation replicates monitor identification so the IPC maintains stable video output during power cycles or hot‑swap.
• What is PDPC (Peripheral Device Power Control)? — PDPC controls power to connected USB peripherals, enabling remote resets and reduced energy use.
• Does the player support digital signage CMS software? — Yes. Supports Windows or Linux OS options and works with browser‑based and native/cloud signage platforms.

Technical specifications

• Model: BPC5023A
• CPU: Intel® Amston Lake Atom® x7433RE Quad‑Core (up to 3.40 GHz)
• Graphics: Gen12 UHD Graphics (up to 32 EU)
• Memory: 1 x DDR5 SO‑DIMM (8 GB or 16 GB)
• Storage: M.2 2280 (64GB SATA3 3D TLC or NVMe 3D TLC options)
• TPM: TPM 2.0 supported
• Video outputs: 2 x HDMI 2.0b (dual independent 4K @ 60Hz)
• Audio: 1 x 3.5 mm line‑out
• Serial: 1 x RS‑232 (RJ‑45) COM1
• Ethernet: 1 x GbE RJ‑45
• USB: 2 x USB 3.2 Type‑A, 1 x USB 2.0 Type‑A
• Wireless: Optional M.2 2230 Wi‑Fi (IEEE802.11 a/b/g/n/ac/ax) + Bluetooth 5.2 kit
• Power: 12 VDC ±10%, 50 W adaptor included (locking DC plug)
• Operating temp: -40° to 70°C (without adaptor); 0° to 45°C (with included adaptor)
• Dimensions: 217 x 22.5 x 123 mm
• Weight: ~1.0 kg
• Mounting: Wall mount kit included
• Security & management: EDID emulation, HDMI‑CEC, PDPC, WoL, Watchdog timer (256 segments)
• Certifications: cULus, CE, RoHS, FCC Class B, IP30
