Pilot freeze dryer Epsilon 2-10D Solvent

stainless steel

Epsilon 2-10D Solvent is specifically designed for the freeze drying of solvents, with particular attention to the selection of components coming in contact with liquids and vapours. This ensures a reliable and sustainable freeze drying process. The unit features a sturdy stainless steel door with a glass window, specifically designed for dealing with solvents. The vacuum required for the process is generated by an oil-free scroll pump with ATEX explosion protection certification as standard. The solvent package is a reliable solution for demanding drying requirements with highly concentrated solvents, such as 100% acetonitrile, 100% dioxane or 60% tert-butanol. A detailed classification of the most commonly used solvents in the categories High, Medium and Low can be found here. Technical data Ice condenser capacity: - 10 kg Ice condenser temperature: - –88 °C Shelf dimensions: - 350 × 400 mm (W x D) Number of shelves: - 3 Shelf area: - 0,42 m2 Shelf spacing: - Shelf temperature: - –55 °C bis zu +60 °C GWP Index: - ≤ 6 Shelf temperature accuracy: - max. ±1 °C Cooling systems: - 2 independent systems, air cooled Ice condenser cooling system: - 2 compressors, 1,2 kW each, in cascade configuration Shelf cooling system: - 1 compressor, 0,9 kW Unit dimensions: - 1295 × 1190 × 850 mm (H x W x D)
