Beam clamp 21 seies

Overview
Mathey Dearman’s Beam Clamp Rollers are designed for overhead pipe handling and installation into racks at refineries, power stations and industrial plants. Units clamp to I‑beams for rapid attachment and offer interchangeable roller heads to handle a wide range of pipe diameters and weights while enabling safe, efficient movement on the worksite.

Product Advantages

• Six configurations covering capacities from 1 to 10 tons
• Three frame sizes accommodating pipe diameters from 2" up to 60"
• Urethane wheels with sealed bearings for smooth operation
• Wheels are bolt‑off and easily replaceable in seconds
• Supplied ready for use on stainless steel models
• Convenient carry handles fitted to all models for safe handling
• Safety leash included with every unit

Technical specifications

• Model 2110 — Beam Clamp Roller (2 – 24" / 60.3 – 610 mm). Load capacity: 1 Ton / 2,240 lb / 1,016 kg. Unit weight: 59 lb / 27 kg. Dimensions L x W x H: 16.5 x 20.5 x 8" / 419.1 x 520.7 x 203.2 mm. Beam flange width: 6 – 12" / 152.4 – 304.8 mm. Shipping dims: 17 x 21 x 8" / 431.8 x 533.4 x 203.2 mm.
• Model 2110HD — Beam Clamp Roller HD (2 – 24" / 60.3 – 610 mm). Load capacity: 3 Tons / 6,720 lb / 3,048 kg. Unit weight: 95 lb / 43 kg. Dimensions L x W x H: 16.5 x 20.5 x 8" / 419.1 x 520.7 x 203.2 mm. Beam flange width: 6 – 12" / 152.4 – 304.8 mm. Shipping dims: 17 x 21 x 8" / 431.8 x 533.4 x 203.2 mm.
• Model 2125 — Beam Clamp Roller (4 – 48" / 114.3 – 1,220 mm). Load capacity: 5 Tons / 11,200 lb / 5,080 kg. Unit weight: 130 lb / 59 kg. Dimensions L x W x H: 19 x 30 x 8.75" / 482.6 x 762 x 222.3 mm. Beam flange width: 6 – 12" / 152.4 – 304.8 mm. Shipping dims: 19 x 30 x 9" / 482.6 x 762 x 228.6 mm.
• Model 2125HD — Beam Clamp Roller HD (4 – 48" / 114.3 – 1,220 mm). Load capacity: 10 Tons / 22,400 lb / 10,160 kg. Unit weight: 180 lb / 82 kg. Dimensions L x W x H: 19 x 30 x 8.75" / 482.6 x 762 x 222.3 mm. Beam flange width: 6 – 12" / 152.4 – 304.8 mm. Shipping dims: 19 x 30 x 9" / 482.6 x 762 x 228.6 mm.
• Model 2135 — Beam Clamp Roller (16 – 60" / 400 – 1,530 mm). Load capacity: 5 Tons / 11,200 lb / 5,080 kg. Unit weight: 145 lb / 66 kg. Dimensions L x W x H: 21 x 34 x 8.75" / 533.4 x 863.6 x 222.25 mm. Beam flange width: 6 – 12" / 152.4 – 304.8 mm. Shipping dims: 21 x 34 x 9" / 533.4 x 863.6 x 228.6 mm.
• Model 2135HD — Beam Clamp Roller HD (16 – 60" / 400 – 1,530 mm). Load capacity: 10 Tons / 22,400 lb / 10,160 kg. Unit weight: 200 lb / 91 kg. Dimensions L x W x H: 21 x 34 x 8.75" / 533.4 x 863.6 x 222.25 mm. Beam flange width: 6 – 12" / 152.4 – 304.8 mm. Shipping dims: 21 x 34 x 9" / 533.4 x 863.6 x 228.6 mm.

General features

• Wheel material: urethane wheels with sealed bearings; bolt‑off replacement for fast maintenance
• Lightweight construction with I‑beam clamp for quick installation
• Ready‑to‑use finish available on stainless steel models
• Carry handles fitted on all models for safe handling
• Safety leash included with every model
• Compatible with beam flange widths 6 – 12" / 152.4 – 304.8 mm
