Measured media: gas, steam, liquid
Measured range(with no shift): 0bar~0.4bar…30bar
Basic error: ±0.075%
Diaphragm contacting with liquid: Stainless Steel 316L, Hast-alloy
Through corrugated, isolated diaphragm and filling oil, process media is pressurized to the diaphragm of the pressure sensor. The other end of the pressure sensor diaphragm is connected to the air (for gauge measurement) or vacuum(for absolute measurement). In such a way, it makes the resistor of the sensor die change so that the detection system outputs a different voltage. The output voltage is in proportion to the pressure variation, and then it is transmitted to standard output by adapter and amplifier.
