Industrial simulator NCSIMUL

CAD/CAMmilling

Overview
NCSIMUL Machine is a CNC machining verification and simulation solution that reproduces machine-specific behavior to verify, simulate and optimize G-code offline. The software creates a realistic work environment matching your machine, tools and materials.

Product summary
Available for turning, drilling and milling (3–5 axis), as well as multi-tasking and highly complex configurations, NCSIMUL Machine supports unlimited channels and directly imports CAM data and tool libraries to avoid rebuilds.

Features at a glance

• G-code verification with high-performance, real-time simulation and an intuitive UI.
• 3D collision detection and detailed material-removal visualization.
• Toolpath optimization: feeds and speeds tuning to reduce cycle times.
• Embedded generation of CNC technical documents and simulation player for review.
• Direct CAD/CAM interfaces for importing CAM data and existing tool libraries.
• Support for 3–5 axis, multi-tasking and complex machine kinematics; unlimited channels.

Challenges addressed

• On-machine collisions and interference during machining.
• Lengthy block-by-block program verification on the shop floor.
• Time lost to air-cutting and incorrect setups.
• Damage to tools, spindles and fixtures from unverified programs.

Benefits

• Reduced collision risk through pre-run verification.
• Less CNC downtime by validating programs offline.
• Confirm G-codes on the PC before machining.
• Optimize toolpaths to decrease cycle time and cost per part.
• Enable safer unattended or lights-out operation.

Capabilities & workflow

• Read and simulate any G-code and machine/tool-builder macros.
• Preview toolpaths and detect errors before target-machine runs.
• Interactive synchronization between 3D view, G-code and information panels.
• Dynamic 3D zoom and material-removal preview for stepwise inspection.
• Centralized access to verification tasks from a single screen for streamlined workflow.
• Turnkey delivery including machine license, service and support.

Caractéristiques / spécifications techniques

• Supported machining types: turning, drilling, milling (3–5 axis), multi-tasking and highly complex machines.
• Machine-accurate dynamic verification using real machine, tool and material characteristics.
• Unlimited channels support to represent complex multi-spindle/multi-turret machines.
• CAD/CAM integration: direct import of CAM files and tool libraries to avoid rebuilds.
• Advanced collision detection and high-fidelity 3D visualization for material removal preview.
• Toolpath optimization tools for feeds and speeds tuning to reduce cycle times.
• Generates CNC technical documentation and supports collaborative review via a simulation player.
• Solution includes machine license, service and support as part of the package.
