Optical data cable MLCBMS-K-30-A-F

connection

MultiLane offers a selection of high bandwidth M-SMPM cables to complement its portfolio of test instrumentation and interconnects. The MSMPM cables are equipped with standard connectors, such as M-SMPM type A and type B, and 1.85, 2.4 and 2.92 mm connectors for different bandwidth options, and are available in different lengths. MultiLane recommends usage of type A with interconnects such as ML4020-MSMPM, QSFP28 HCB. In addition, MultiLane offers a selection of type B M-SMPM cables to complement its 400G ML4079D and 800G ML4079E BERT instruments. Key Features General MultiLane offers both type A and B to provide connectivity to its Interconnects and Instruments. Type B is equipped with a bolted latching mechanism. The cable assemblies consist of 4 pairs of phase matched cables (8 cables) with maximum intrapair skew of the phase matched cable pairs of 1 ps. In addition, the cables offer excellent insertion loss and return loss performance for optimum signal integrity when using high port count instruments or test fixtures. Target Applications • Test instrumentation connection to DUT eval boards • Connecting interconnects, such as MCB and HCB to test instruments
