Pneumatic press A1 seriesmechanicalformingbending
Add to favorites
Compare this product
Characteristics
- Operation
- pneumatic, mechanical
- Function
- forming, bending, punching, process, blanking
- Applications
- for sheet metal, for steel, for aluminum
- Structure
- C-frame
- Control
- PLC-controlled
- Other characteristics
- cold, high-speed, economical, high precision
- Force
Max.: 315 tf
Min.: 25 tf
- Rate (strokes/min)
Max.: 190 p/min
Min.: 20 p/min
- Stroke
Max.: 250 mm
(9.843 in)Min.: 30 mm
(1.181 in)- Weight
Max.: 30 t
(33 us ton)Min.: 2 t
(2 us ton)- Overall length
Max.: 1,740 mm
(69 in)Min.: 832 mm
(33 in)- Overall width
Max.: 2,345 mm
(92 in)Min.: 1,060 mm
(42 in)- Overall height
Max.: 4,200 mm
(165 in)Min.: 2,165 mm
(85 in)
Description
Goanwin is a big manufacturer of presses for metal stamping industries in China.
Press type: C-Frame single crank mechanical press
Tonnage: 25-400ton
Application:
This stamping press is generally applicable for blanking, punching, bending and forming process on small single work of thin steel plate and progressive die parts, which can connect with single press, progressive die, mechanical arm or added with transfer system.
Features:
High torque, low noise clutch and brake.
-Rigid frame with less deflection.
-High accuracy transmission gears and high rigidity crank ensure press long life and accuracy.
-Forced Lubrication system with default monitor ensures the operation reliability.
-User-friendly design and electric control system providing high automation compatibility.
Please review the specifications of A1 Series presses on our catalogue , and contact us for assistance to choose the right one for your production.
Goanwin presses can be customized to meet a wider range of SPM, stroke, rating point (BDC), bed and other specifications and dimensions.
