Diesel engine concrete mixer UTIMEC LF 600

mobilefor underground mining

Overview
Utimec LF 600 transmixer with a concrete carrying capacity of 5.6 m3 is designed for concrete transportation in underground mines and tunnels where tramming height is 2.6 m or more. It features a robust concrete drum with electrically controlled mixing and unloading and a manual drum locking system. The vehicle includes a FOPS/ROPS approved cabin, a front axle suspension system as standard and several safety features.

Key specification

• Type: Concrete transmixer
• Carrying capacity: 5.6 m3
• Tramming height requirement: 2.6 m

Features - Safety

• FOPS/ROPS approved cabin
• Improved visibility with maximized window area and heated wide-angle mirrors
• Cabin door interlock switches with automatic safety brake application
• Optional reversing camera system for enhanced rear visibility
• SAHR fail-safe parking brakes
• Engine brake

Features - Sustainability

• Available with low-emission Stage V engine technology

Features - Ergonomics and operator environment

• Normet cabin designed with operator ergonomics and safety as priorities
• Advanced front axle suspension system for improved ride quality
• Air-suspended T-back driver’s seat with 3-point seat belt
• Multifunctional display providing key driving information

Features - Productivity and efficiency

• Robust concrete drum
• Electrically controlled mixing and unloading
• Manual drum locking system
• Drum rotation speed adjustable 0-13 RPM
• Adjustable drum discharge height 1450-2000 mm
• Optional hydraulically operated discharging hatch
• Optional remote controller for the concrete drum
• Optional form oil system with a 30 l tank
• Optional accelerator transfer system with a 250 l tank and hydraulic-driven pump
• Optional emergency drum emptying
• Optional oil cooler for drum rotation
• Optional retarder
• Optional lock for drum lifting
• Optional hydraulic concrete drum brake
• Optional hydraulic front support legs
• Optional pressure washer with a 230 l tank

Technical specifications

• Model: Utimec LF 600
• Carrying capacity: 5.6 m3
• Tramming height requirement: 2.6 m or more
• Drum type: robust concrete drum with electrically controlled mixing and unloading
• Drum rotation speed: adjustable 0-13 RPM
• Adjustable drum discharge height: 1450-2000 mm
• Manual drum locking system
• FOPS/ROPS approved cabin
• Front axle suspension system (standard)
• Heated wide-angle mirrors; maximized cabin window area for improved visibility
• Cabin door interlock switches with safety brake application
• Optional reversing camera system
• SAHR fail-safe parking brakes and engine brake
• Optional hydraulically operated discharging hatch
• Optional remote drum controller
• Optional form oil system: 30 l tank
• Optional accelerator transfer system: 250 l tank with hydraulic pump
• Optional emergency drum emptying and oil cooler for drum rotation
• Optional retarder, lock for drum lifting, hydraulic concrete drum brake, hydraulic front support legs
• Optional pressure washer with 230 l tank
• Available with low-emission Stage V engine technology
