Diaphragm seal with flange connection 29

process

An off-line seal with a threaded connection and all welded, all metallic housing design that does not utilize an o-ring or gasket Can be used for remote mounting of pressure instrument(s) with capillary, see options & accessories below Designed with a larger diameter diaphragm for higher displacement capability A variety of upper and lower housing and diaphragm materials are available to suit most applications A flushing port is available to clean wetted areas and prevent process media build up Consider instrument size, pressure range, media composition, ambient and operating temperature, and maximum working pressure when selecting Capillaries and cooling elements are available for elevated process temperatures, see options & accessories below Fill fluid must be compatible with process media; i.e. Glycerin may become volatile in conjunction with a strong oxidizing agent such as chlorine, forms of oxygen or peroxide and nitric acids Seal type - Threaded with welded diaphragm Instruments - Type - Size - Minimum Pressure - Maximum Pressure Gauges - 2-1/2" to 4-1/2" - 0 psig to 30 psig - 0 psig to 2,500 psig Transducers - — - 0 psig to 30 psig - 0 psig to 2,500 psig Switches - — - 0 psig to 30 psig - 0 psig to 2,500 psig
