Reversible vibratory plate VDR 22

gasoline engine

RANGE series plates are the next step in the development of the manipulation possibilities of vibratory plates. Due to their weight and performance characteristics, light reversible plates are an alternative to forward vibratory plates with better optimization of handling properties, mainly due to the possibility of revers. In addition it provide trouble-free work in confined spaces where it is very difficult or impossible to handle with forward vibratory plates. Operational parameters Plate width 400 mm Centrifugal force 22 kN Frequency 100 Hz Max. speed 24 m/min Electric start No Engine Maker and type Honda GX 160 Fuel Petrol Net power 3,6 kW Emission stage EU Stage V Operational fluids Water tank capacity 10 l Working dimensions Lenght 1180 mm Width 400 mm Height 990 mm Transport dimensions Lenght 685 mm Width 400 mm Height 1090 mm
