Forward travel vibratory plate VD 15
gasoline engine

forward travel vibratory plate
forward travel vibratory plate
forward travel vibratory plate
forward travel vibratory plate
forward travel vibratory plate
forward travel vibratory plate
forward travel vibratory plate
forward travel vibratory plate
Add to favorites
Compare this product


Characteristics

Type
forward travel
Other characteristics
gasoline engine
Weight

85 kg
(187.39 lb)

Description

An ELEGANT series machines are an evolutionary step in our range of forward vibratory plates. The concept was based on market requirements such as ergonomics, versatility and design. This series was designed as an response to the large number of requirements for modern machines combining efficiency, performance and style. For the Elegant series there is used an unique design of handle which is integrated to the protecting frame. The concept of "all-in-one" allows work on all kind of surfaces with no need of extra accessories. Operational parameters Plate width 400 mm Centrifugal force 15 kN Frequency 100 Hz Max. speed 25 m/min Engine Maker and type Honda GX 160 Fuel Petrol Net power 3,6 kW Emission stage EU Stage V Operational fluids Water tank capacity 12 l Working dimensions Lenght 1200 mm Width 400 mm Height 930 mm Transport dimensions Lenght 695 mm Width 400 mm Height 745 mm
