Voltage input module CT-3168

analog8-channel8 analog inputs

CT-3158: 8 Channel Voltage Input 0~5VDC/0~10VDC/±5VDC/±10VDC, 12Bit Module features ◆ The module supports 8 channels of voltage signal input ◆ The module could collect 0~5VDC, 0~10VDC, ±5VDC, ±10VDC, with a 12-bit resolution ◆ The module carries with 8 analog input channel LED indicator ◆ The module input signal is a single ended common grounding input Technical Parameters General parameters Power: [email protected] Isolation: I/O to internal bus: opto-couple isolation (3KVrms) Field Power: Not used Wiring: I/O wiring：Max.1.5mm2(AWG 16) Mounting Type: 35mmDIN-Rail Size: 115*14*75mm Weight: 65g Environment Specification Operational Temperature: -40~85℃ Operational Humidity: 5%~95% RH(No Condensation) Protection Class: IP20 Input Parameter Channel Number: 8 channel voltage input LED Indicator: 8 channel input indicators Input Voltage Range: 0~5VDC、0~10VDC、±5VDC、±10VDC Resolution: 12Bit Accuracy ±0.3%@25℃ ±0.5@-40~85℃ Output Impedance: 1MΩ Common Terminal: Common Grounding Input
