Analog I/O module CT-3713

CANopenEthernetModbus RTU

CT-3713: 3-channel RTD-PT100 temperature acquisition module Module features ◆ The module supports 3-channel RTD thermal resistance (PT100) temperature acquisition ◆ The module could be connected to a 2-wire or 3-wire PT100 temperature sensor ◆ The internal bus of the module and field input adopts magnetic isolation ◆ The module carries with 3 analog input channel LED indicator ◆ 15-bit ADC resolution Technical Parameters General parameters Power: [email protected] Isolation: I/O to internal bus: magnetic isolation (2.5KVrms) Field Power: Not used Wiring: I/O Wiring：Max.1.5mm2(AWG 16) Mounting Type: 35mmDIN-Rail Size: 115*14*75mm Weight: 65g Environment Specification Operational Temperature: -40~85℃ Operational Humidity: 5%~95% RH(No Condensation) Protection Class: IP20 Input Parameter Channel Number: 3 Channels LED Indicator: 3 Green LED Resolution: 15 bit Sensor Type: PT100 Measurement Range: -240~880℃ Measurement Accuracy: 0.5℃ Single Channel Conversion Time: MAX.21ms
