Tracked mini dumper PUMA 600

gasolinegasoline enginefront-loading

Short description
Front-discharge dumper body with a self-loading shovel for efficient material handling in confined construction and renovation sites.

Overview
The Puma Minidumpers are compact, powerful machines engineered for construction and renovation tasks where space is limited. Hydrostatic transmission and a high-performance gear pump (up to 210 bar) provide controlled operation and strong hydraulic performance. Standard electric start HONDA engines ensure reliable ignition.

Key features

• Front-discharge dumper body for fast unloading
• Self-loading shovel for one-operator loading
• Hydrostatic transmission for precise control
• High-performance gear pump (up to 210 bar)
• Compact dimensions suitable for confined areas
• Quick couplings and support stand for rapid attachment changes

Safety and chassis
2 OVERCENTER VALVES
Valves prevent speed increase during descent under load and ensure stability when parked on uneven ground.

ROLLER BALANCED SYSTEM
PUMA 600 is fitted with three fixed rollers per side to ensure safe obstacle negotiation.

TRACKS – TRACK TENSIONERS
Recovery springs in the tensioning system prevent jerks and protect tracks and drive components. Long track base and multiple support rollers per side allow operation on rough or sloped terrain up to 30% gradient.

HONDA ENGINE
Standard electric start system for easy and reliable ignition.

HYDRAULIC SYSTEM
High-performance gear pump delivers up to 210 bar. No radiator required as oil temperature stays within safe limits under heavy use.

UNDERCARRIAGE
Low center-of-gravity chassis for stability on all terrains. Constructed from carbon steel (min. 5 mm) with 160 mm ground clearance and lifting hooks for transport.

OPERATOR PLATFORM
Large, non-slip, vibration-damping and foldable platform to improve comfort and reduce storage footprint.

Attachments & Versatility
Dual-speed transmission on applicable models for faster on-site movement. Compatible with multiple attachments; quick couplings and support stand included as standard for rapid changes.

caractéristiques / spécifications techniques

• Models compared: 500 / 600 / 800
• Engine: 500 = HONDA GX 200; 600 = HONDA GX 270; 800 = HONDA GX 390
• Engine power (kW / rpm): 500 = 4.1 / 3600; 600 = 6.6 / 3600; 800 = 9.5 / 3600
• Fuel tank capacity (L): 500 = 3.1; 600 = 5.3; 800 = 10
• Oil tank (L): 500 = 14; 600 = 14; 800 = 20
• Starting system: 500 = Manual; 600 = Electric; 800 = Electric
• Transmission: Hydrostatic (all models)
• Hydraulic motors: Orbital (all models)
• Travel speed (km/h): 500 = 1 speed — 2.0 / 3.6; 600 = 2 speeds — 2.5 / 3.5; 800 = 2 speeds — 2.5 / 3.5
• Operating load: 500 = 500 kg on flat ground — 350 kg on slope; 600 = 600 kg on flat ground — 350 kg on slope; 800 = 800 kg on flat ground — 600 kg on slope
• Skip capacity (m³): 500 = 0.21; 600 = 0.21; 800 = 0.32
• Maximum gradient: 30% for all models (800 specified as 30% (17°))
• Track dimensions (mm): 500 = 180 × 60 × 38; 600 = 180 × 60 × 38; 800 = 200 × 72 × 40
• Track tension adjustment: Semi-automatic spring tensioning system (all models)
• Packaging dimensions (cm): 500 & 600 = 80 × 160 × 135; 800 = 80 × 200 × 165
• Weight with packaging (kg): 500 = 425; 600 = 485; 800 = 750
