Internal cylindrical grinding machine GI-20NII

workpieceCNC2-axis

Our GI-20N high-speed I.D. CNC grinder delivers accuracy and power in a compact design. Capable of simultaneous 2-axis control, this model is extremely flexible in handling a wide variety of workpiece shapes in a simple data setting. Centralized control of lubricating and pneumatic devices allows for easy maintenance, while simplified programming and the program help function allow for easy operation. PART CAPABILITIES - up to 11.81” ID and up to 11.81” max grind length WIDE RANGE OF GRINDING WHEEL SPINDLES – Belt drive up to 40,000 RPM High frequency up to 150,000 RPM 5 SURFACE HYDROSTATIC GUIDEWAYS - High rigidity, accuracy and durability OSP-P300GA CONTROL - easy operation with IGAP+ conversational programming FLEXIBLE FOR A VARIETY OF PART SIZES- Available with a single wheel spindle, 2 wheel spindles or 4 wheel spindles Highlighted Specs Bore Range - with 100mm (3.95) OD Wheel (mm) Ø5-300 Max Grinding Length - 1WS/2WS (mm) 200 Max Grinding Length - Center Rest Option (mm) 300 Max Grinding Length - 4WS (mm) 130 Workhead Spindle Bore (mm) Ø70 Rapid Traverse (m/min) 12
