AC servo-drive NXD20 series

for servo motorsfront panel100/110/115 V

servo motor drivers allow for easy operation and control of the servo motors. 4 Control Modes are available: Position, Speed, Torque and Tension Control. The driver provides automatic tuning allowing for optimal performance without manual adjustments. Built-in Protective Functions Pulse Input Type Single-Phase 100-115 VAC, Single-Phase 200-230 VAC, Three-Phase 200-230 VAC Works with NX Series Tuning Free Servo Motors* Easy Operation As with a stepping motor, stable operation can be achieved in high inertia drive and belt mechanism drive applications without gain adjustment using the servo motors. Also, adjusting the gain manually enables operation under even more stringent load conditions. Achieves High Inertia Drive With automatic tuning, operation up to 50 times the rotor inertia is possible. With manual tuning, operation up to 100 times the rotor inertia is possible. Achieves Smooth Operation with Belt Mechanisms Belt mechanisms can be operated with the same performance as a stepping motor without the occurrence of vibration before stopping. Driver Operation Easy Handling Basic settings and adjustments are made with switches and potentiometers on the front panel. This design allows for easy control without a computer and even saves the hassle of complicated UP and DOWN key operations.
