Compression disc spring GN 509.3
conicalsteel

Compression disc spring - GN 509.3 - Otto Ganter GmbH & Co. KG - conical / steel
Compression disc spring - GN 509.3 - Otto Ganter GmbH & Co. KG - conical / steel
Compression disc spring - GN 509.3 - Otto Ganter GmbH & Co. KG - conical / steel - image - 2
Add to favorites
Compare this product
Go to the Otto Ganter GmbH & Co. KG website for more information

Characteristics

Function
compression
Type
conical
Material
steel
Outer diameter

Min.: 31 mm
(1.2 in)

Max.: 55 mm
(2.2 in)

Description

Clamp spring washers GN 509.3, type A allow ball transfers units to be mounted and removed from the installation side. Retaining rings GN 509.3, type B are mounted from the back. Ball transfers units mounted this way can no longer be dismantled. No restrictions exist with respect to sheet metal thickness.
