Water-cooled motor 009162
brushlessDCuniversal

Water-cooled motor - 009162 - OZO - brushless / DC / universal
Water-cooled motor - 009162 - OZO - brushless / DC / universal
Water-cooled motor - 009162 - OZO - brushless / DC / universal - image - 2
Water-cooled motor - 009162 - OZO - brushless / DC / universal - image - 3
Water-cooled motor - 009162 - OZO - brushless / DC / universal - image - 4
Water-cooled motor - 009162 - OZO - brushless / DC / universal - image - 5
Water-cooled motor - 009162 - OZO - brushless / DC / universal - image - 6
Add to favorites
Compare this product
Go to the OZO website for more information

Characteristics

Type
DC, brushless, universal
Voltage
48 V, 60 V, 72 V
Configuration
permanent magnet, central
Protection class
IP64
Number of poles
10-pole
Cooling mechanism
water-cooled
Applications
for boat, for medical equipment, for pump, for automatic distributors, for wheelchairs, for drive systems, for frequent stop/start applications, mill duty, for the pharmaceutical industry, propulsion, for switchgear, for electric actuators, for circuit breakers, for vertical loading, for space applications, for furniture level adjustment, for deep well, for lawn-mowers, for electrical apparatuses, for dental instruments, for fitness equipment, for sewing machine, centrifuge, for heavy machinery, for surgical power tools, for collaborative robots, for delivery robot, for the petroleum industry, for roadheader, for the electronics industry, for wind turbine, for motorcycles, for air purifiers, for conveyors, for roller conveyors, for elevators, blower, fire pump, for washdown applications, for mixers, hospital ventilators, for roller shutters, for the textile industry, for the food industry, for automotive applications, for the semiconductor industry, for retrofitting, for electric powertrains, for oil rig, for cutting machines, for the metallurgical industry, for garbage disposals, for the plastics industry, for vacuum pumps, for circular saws, for machine tools, for robotic lawnmowers, for forming machines, for fans, for marine applications, for washing machines, for food industry machinery, for floor scrubbers, for crusher, for hair dryers, distribution, packaging machine, for furnaces and ovens, for the paper industry, for power tools
Other characteristics
high-performance
Power

15,000 W
(20.39 hp)

Intensity

231 A

Torque

12 Nm
(8.850746 ft.lb)

Rotational speed

3,000 rpm
(18,849.5559 rad.min-1)

Operating temperature

Min.: -10 °C
(14 °F)

Max.: 50 °C
(122 °F)

Description

This central rotor Brushless BLDC motor is designed to deliver a power of 15,000W (15kW) at 48V, 60V, 72V, or 84V. It will enable you to convert your pleasure or fishing boat, sailboat under 15 meters, or your old motorcycle or karting to electric power... Note that to make the installation easier, OZO can offer you motor mounts or frames in 304 or 316 stainless steel, suitable for electric karting or retrofitting on boats or sailboats, and assist you in creating the liquid cooling system. The support is to be bolted or welded to your hull or chassis in place of the thermal engine. This central rotor IPM Brushless motor has a maximum rotational speed of 5500 rpm. Supplied with 48V DC, its rotational speed will be 4000 rpm. This motor has 5 pairs of poles. The advantage with electric motors is that everything is adjustable via power electronics: torque, acceleration ramp, braking ramp, engine braking force, acceleration dead time, engine speed, etc. You can retain your throttle controls or original accelerator handle since the electronic accelerator is directly connected to the original cable. The cable pull is therefore preserved. It is preferable to power this motor with a Lithium battery of 48V DC or 60V or 72V or 84V depending on the desired performance.
