Hydraulic hose GlobalCore 797
fuel oilsynthetic rubbersteel

hydraulic hose
hydraulic hose
Add to favorites
Compare this product


Characteristics

Use
hydraulic, fuel oil
Material
synthetic rubber, steel
Applications
construction, for petrochemical applications, agricultural, for mining applications, military
Other characteristics
lightweight, standard, rugged, spiral, wire-braided
Inner diameter

Max.: 2 in

Min.: 0.25 in

Pressure

6,000 psi

Temperature

Max.: 125 °C (257 °F)

Min.: -40 °C (-40 °F)

Description

Parker’s 797 hose, within the GlobalCore product line, was designed to deliver consistency and reliability with a constant working pressure of 6,000 PSI in all sizes. The 797 hose is made with Compact Spiral technology making it light, durable, and easily bent making installation easier and quicker. The 797 hose is designed, built and tested to the ISO 18752 performance specifications. Sizes range from ¼” to 2” in diameter with different cover options available for various markets. Markets: • Military • Construction • Forestry • Oil Field Service • Industrial • Mining Features/Benefits: • - Standard, ToughCover or SuperTough cover options to prevent abrasion • - Half SAE bend radius for ease of installation and low force to flex • - 30% smaller O.D. compared to standard SAE spiral hose • - 6,000 PSI constant working pressure in ail sizes • - Less hose weight than SAE spiral • - Twice the impulse/life for a longer useful life of the hose • - Flex impulse tested to provide a superior hose in both performance and service life Applications: • - Petroleum base hydraulic fluids and lubricating oils Compatible Fittings: • - 43 sériés fittings (for -4 to -6) • - 77 sériés fittings (for -8 to -32)
