Diesel engine E70B

6-cylinderturbochargedin-line

Overview
Designed for vessel auxiliary power, the E70B supplies on-board electricity with fast starting, low noise and low emissions. It is intended for continuous and heavy-duty auxiliary applications where a dedicated engine is preferable to generating electricity from the propulsion engine.

Features At A Glance

• Service intervals: 500 hours standard; comprehensive warranty cover (2 years standard, 3 years on major components).
• Configurable: choice of standard build configurations to match diverse auxiliary application requirements.
• Global support: over 80 years of experience with worldwide distributor and service network providing parts and exchange units 24/7.

Key Specs

• Maximum Power: 290 hp / 216 kW
• Bore: 105 mm (2.7 in)
• Stroke: 135 mm (3.4 in)

Product Specifications
Power Rating
Maximum Power: 290 hp / 216 kW
Rated Speed: 1500/1800 rpm

General
Bore: 105 mm (2.7 in)
Stroke: 135 mm (3.4 in)
Displacement: 7 l (427 in³)
Aspiration: Turbocharged aftercooled
Rotation from Flywheel End: Anti-clockwise
Total Lubricating Capacity: 21 l (5.5 gal US)
Compression Ratio: 16.5:1
Number of Cylinders: 6 vertical inline
Combustion System: Direct injection
Total Coolant Capacity: 35.5 l (9.3 gal US)
Cooling System: Liquid
Cycle: 4 stroke

Engine Dimensions*
Dry Weight: 1212 kg (2672 lb)
Length - Flywheel Housing: 1368 mm (53.8 in)
Height: 1132 mm (44.5 in)
Width: 836 mm (32.9 in)

Standard Equipment
Air inlet system

• Air filter
• Inlet air restriction indicator
• Filtered CCV
• Water jacketed turbocharger
• Water jacketed exhaust manifold

Control system

• Full electronic control system
• Engine harness with IP55 Customer connect for engine sensors and SAE J1939 CAN bus
• Cold start aid, ECM controlled to -15 °C (5 °F)

Cooling system

• Gear driven fresh and auxiliary water pumps
• Thermostatically controlled cooling water system
• Galvanically neutral anode free system

Flywheels and flywheel housing

• SAE2 and SAE3
• Single and dual starter position

Fuel system

• High pressure common rail system
• Self priming
• Engine mounted fuel filter

Oil system

• High inclination oil sump
• Integral plate type engine oil cooler
• Engine mounted oil filter

Disclaimer
Final dimensions dependent on selected options.

Technical Specifications

• Maximum Power: 216 kW (290 hp)
• Rated Speed: 1500/1800 rpm
• Bore: 105 mm (2.7 in)
• Stroke: 135 mm (3.4 in)
• Displacement: 7 l (427 in³)
• Aspiration: Turbocharged aftercooled
• Number of Cylinders: 6 vertical inline
• Combustion System: Direct injection
• Compression Ratio: 16.5:1
• Total Lubricating Capacity: 21 l (5.5 gal US)
• Total Coolant Capacity: 35.5 l (9.3 gal US)
• Dry Weight: 1212 kg (2672 lb)
• Dimensions (L×H×W): 1368 mm × 1132 mm × 836 mm (53.8 in × 44.5 in × 32.9 in)
• Cooling System: Liquid, 4-stroke cycle
