Industrial vacuum cleaner XTRACTOR 3BP

dryhazardous dustdust

Description
The industrial vacuum XTRACTOR 3BP is a compact, mobile solution designed for professionals in construction and floor treatment. It provides reinforced filtration, high maneuverability and hygienic dust disposal for on-site operations.

Key features

• Three independent single-phase by-pass motors totaling 3.45 kW, offering adjustable power and stable suction with double-ventilation cooling integrated on each motor.
• Maximum vacuum 2,500 mmH2O and maximum airflow 540 m³/h for effective extraction of fine dust (sanding, planing, cutting).
• Filtration based on three polyester M-class cartridges with PTFE treatment (total filter area 57,000 cm²) and pneumatic reverse-pulse automatic cleaning controlled by a timer.
• Optional HEPA H14 filter (26,000 cm²) for hazardous dust applications — 99.995% efficiency at 0.18 μm.
• Longopac continuous bagging system (20 m tubular bags) for hygienic, contact-free dust disposal.
• Adjustable chassis with two gas springs to lower the height for transport in vans or trailers without disassembly.
• Epoxy-painted steel construction, reinforced multidirectional wheels and ergonomic push handle for easy maneuvering on site.

Applications

• Extraction of concrete dust.
• Floor cleaning after sanding.
• Secure collection of fine and hazardous dusts (silica, asbestos) in confined worksites, with HEPA H14 filtration option.

Technical specifications

• Model: XTRACTOR 3BP
• Motors: 3 independent single-phase by-pass motors
• Total power: 3.45 kW
• Maximum vacuum: 2,500 mmH2O
• Maximum airflow: 540 m³/h
• Primary filtration: 3 polyester M-class cartridges with PTFE treatment
• Total filter area: 57,000 cm²
• HEPA option: H14 (26,000 cm²) — 99.995% efficiency at 0.18 μm
• Cleaning system: pneumatic reverse-pulse automatic (timed)
• Collection system: Longopac continuous bagging (20 m tubular bags)
• Voltage: 230 V
• Collection capacity: Longopac (continuous bagging)
• Construction: epoxy-painted steel, industrial chassis
• Mobility: adjustable chassis with two gas springs, reinforced multidirectional wheels, ergonomic handle
