V belt PIX-Enforcer®-XSrubberagriculturalfor harvesters
Add to favorites
Compare this product
Characteristics
- Type
- V
- Material
- rubber
- Product applications
- agricultural, for harvesters
- Other characteristics
- high-performance, wrapped, high-power, high wear resistance, aramide-corded
- Length
Max.: 196 in
Min.: 46 in
- Width
13 mm, 17 mm, 22 mm
(0.512 in, 0.669 in, 0.866 in)- Thickness
8 mm, 10 mm, 11 mm
(0.31 in, 0.39 in, 0.43 in)- Temperature
Max.: 100 °C
(212 °F)Min.: -25 °C
(-13 °F)
Description
Features
- Superior power transmission capacity as compared to standard Belts
- Specially treated outer cover fabric for high wear resistance
- Specially coated aramid cord enhances the adhesion strength and offers minimum elongation
- Unique design in wrap construction to facilitate operation on smaller pulley diameters with an acute reverse bend
- High performance in variable load & reverse idler drives
- Longer service life
- Extended temperature range: -25°C to + 100°C
Constructional Details
1.Special top fabric layer
2.Adhesion rubber
3.Especially treated aramid tensile member provides extra strength & low belt stretch
4.High modulus rubber base compound
5.Multi-layer fabric provides extra strength & act as a crack barrier during the reverse bend
Applications
Rice harvesters, planters, etc.
