Torsion test machine WFT-01

forceautomaticmaterial

WFT-01 Push Force Tester for Guidewire and catheter is used to test and record the characteristics of intravascular medical devices (including balloon catheters, guide wires and stent delivery systems). This system is used to simulate the tracking force and pushing efficiency of products under human blood vessels. A variety of test combinations can be provided, and the test results can be used for routine data analysis to evaluate product performance. Standards ASTM F 2394-2007, YY0807-2010, YY/T0663.2-2024 Mark: Can be customized according to requirements Technical Features Adopt micro-range dynamic torque and force sensors, which can sense the tiny force changes Using a high-precision angle sensor, which can test the rotation angle Panasonic servo motor and reduction system, stable and efficient Equipped with high-precision water bath circulation temperature control device, water inlet and outlet, temperature control of blood vessel model The movable slider carries angle and torque sensors, and different sensors can be switched for angle and torque measurement Provide historical data backup management function, which can perform diversified analysis of historical test data Computer software control system, which can realize real-time curve analysis and facilitate data processing and transmission Maximum value, minimum value, average value can be displayed and test report can be generated, the test report can be printed by micro-printer Equipped with an overflow return device, the blood vessel model and the inlet port are submerged in water to ensure the horizontal state during the test.
