Horizontal injection molding machine S0 series

hydraulicfor elastomersfor parts with insert

Overview
S0-Series injection molding presses for insert molding and extended production runs. Available in three frame sizes (S03, S05, S06) with Y10/Y20 configuration options to match different injection capacity requirements. Suitable for molding parts such as housing seals and other insert-molded components.

Version S03 Y10

• Clamping force: 3,200 kN
• Heater plate dimensions: 1,250 x 630 mm
• Injection capacity: 1000 cc

Version S05 Y10

• Clamping force: 5,000 kN
• Heater plate dimensions: 1,500 x 630 mm
• Injection capacity: 740 cc

Version S06 Y10 or S06 Y20

• Clamping unit: 6,000 kN
• Injection capacity: 1,000 cc or 2,000 cc

Technical specifications

• Series: S0-Series
• Intended application: insert molding (e.g. housing seals) and long production runs
• Available frame sizes: S03 (300t), S05 (500t), S06 (600t)
• S03 Y10 – Clamping force: 3,200 kN; Heater plate: 1,250 x 630 mm; Injection capacity: 1000 cc
• S05 Y10 – Clamping force: 5,000 kN; Heater plate: 1,500 x 630 mm; Injection capacity: 740 cc
• S06 Y10/Y20 – Clamping unit: 6,000 kN; Injection capacity options: 1,000 cc or 2,000 cc

Applications

• Insert molding of housings, seals and components with embedded inserts
• High-volume or continuous production runs requiring consistent clamping and injection capacity
• Integration with standard tooling for thermoplastics and elastomers
