Centrifugal pump RW 350 Ewaterelectrichigh-pressure
Add to favorites
Compare this product
Characteristics
- Technology
- centrifugal
- Fluid
- water
- Operation
- electric
- Applications
- high-pressure
- Other characteristics
- with electronic control, with variable-speed controller, soundproof
- Flow
21 m³/h
(741.608 ft³/h)- Pressure
200 bar
(2,900.755 psi)- Power
132 kW
(179.47 hp)- Length
2,400 mm
(94 in)- Width
1,108 mm
(43.62 in)- Height
1,310 mm
(51.57 in)- Weight
2,500 kg
(5,511.56 lb)
Description
Description
High-pressure pump with 132 kW electric motor for water-fed down-the-hole (DTH) hammers, equipped with an inverter and preset speed matched to the hammer in use.
Technical features / specifications
High-pressure pump with 132 kW electric motor for water-fed down-the-hole (DTH) hammers, equipped with an inverter and preset speed matched to the hammer in use.
- Max flow: 350 l/min
- Max pressure: 200 bar
- Control cable extension on reel: 50 m
- Silenced version available
Technical features / specifications
- Motor: electric, 132 kW
- Control system: inverter with preset speed based on hammer
- Max flow: 350 l/min
- Max pressure: 200 bar
- Control extension: 50 m reel
- Version: silenced available
