Control electrical enclosure IBGTflex7050S

DIN railsurface-mountedplastic

Product information
The IBGTflex7050S support frame is designed for mounting DIN-rail devices on the control cabinet door. It provides a recessed mounting area closed from the front by cover plates to prevent visibility into the cabinet.

The frame is fixed to the cabinet door with 4× M6 screws (included). Fasteners for securing the DIN rail and rivets for the side parts are supplied. Cut edges are concealed by the surrounding frame. Protection class IP54 is achieved by a continuous polyurethane seal. The front can be locked using lock 3524E. Refer to the drawing for overall dimensions and cutout details.

Downloads available (names / formats)

• Tender Texts — 00003040_A00003040 .txt
• Technical Description — 00003040_B00003040 .txt
• Technical Description (English) — 00003040_B00003040UK .txt
• Data Sheet — 00003040_ID00003040 .pdf
• Technical Data — 00003040_TD00003040 .txt

Technical specifications

• Model: IBGTflex7050S
• Denomination: IBGTflex7050S
• Front configuration: 2x 50RU, 6U
• Cutout dimensions: 277 x 279 mm (as stated in title/drawing)
• Intended use: mounting DIN-rail devices in the control cabinet door
• Front closed by cover plates (custom-manufacturable)
• Mounting: fixed to door with 4× M6 screws (included)
• Included fasteners: screws for DIN rail, rivets for side parts
• Cut edges covered by surrounding frame
• Ingress protection: IP54 via continuous polyurethane seal
• Lockable: compatible with lock 3524E
• Weight: 0.8 kg
• Product number / SKU: 00003040
• Manufacturer: romutec Steuer- und Regelsysteme GmbH
• Release date (meta): 2026-04-28
