Linear transfer machine BFK2/E5-TR
CNC6-positiondrilling

linear transfer machine
linear transfer machine
Add to favorites
Compare this product


Characteristics

Type
linear
Control type
CNC
Number of positions
6-position
Other characteristics
drilling, automatic, 5-axis

Description

Carrousel Transfer Machine with two drilling and filling stations, with 5-Axis PC-control programming free-, for the production of parallel brushes and with spread on the ends, up to 600 mm in one operation Tool size: 1,8 – 8,5 mm Tool stroke: 65 - 165 mm Materiallength: 40 - 360 mm (unfolded) Production of brushes and brooms, with spread on the ends, up to 600 mm in one operation, with hole-covering Automatic Transfer of brush bodies to the machine. No changing of the brush bodies from drilling to filling. Control of failure and breakdown by indicator High speed, simple and quick changing from one model to the other. Home manufacturing of brush programmes automatically, manually by keyboard or ,“Teach-In method“. Optional automatically labelling of brush bodies Optional trimming aggregates Machine speed: up to 900 bundles / min Noise Level: 75 dB Electrical connection: 6,5 KW Weight: 4200 kg, net Dimensions: approx. D: 3,00 m W: 4,50 m H: 2,30 m
