Dust chamber SM-SC-1000C

climatictemperaturesand corrosion

Structure: 1.Use imported touch screen programmable controller, can control dust blowing motor, dust vibration and test time. 2.With sealing good chamber door, has lock device and glass observation window.There is lamp and dust brush to ensure easy observation of inner chamber. 3.With strong dust blowing device and vibrator to ensure informity of each blowing. 4.Circulating air supplying device: Frequency converter and high pressure motor to ensure the air volume more precision. 5.Large diameter strong stainless steel air hose, covered with heating device, can heat and dry the test chamber dust. 6.Anti-explosion handle, easy operation, strurdy and durable. 7.Imported high-precision electronic temperature humidity sensor and air speed sensor. 8.Test sample differential pressure test device, can set pumping rate freely according to sample inquiry. 9.There is a ψ50mm test hole on the left chamber and equipped with port lid and silica gel chock plug. Through this hole can connect to outer test device. 10.There are casters with brake equipments and fixing foot pad to make the machine easy operation and level adjustment. 11.With voltage current indicator, equipped with corresponding sample DC12V power, DC24V / 20 a, interval, continuous power supply adjustable. Dust concentration wind speed regulating function. May control test total time, blow the dust of time interval and blowing dust cycle and sample with the power source of the intermittent time. 12.Vacuum system: Equipped with pressure meter, air filtration, dust dehumidification system, regulating triple pieces,connecting pipe (Vacuum pump should be prepare by customer)
