Tensile test machine SM-8007

fatiguehardnessbending

Typical applications - Rubber/plastic tensile test Plastic bending test Cable and wire tension test High elastic material tensile test Fabric tearing test Shoe material tensile & tearing test Specification Model - RS-8007 Capacity(optional) - 50N, 100N, 200N, 500N, 1KN, 2KN, 5KN Unit(switchable) - N, KN, Kgf, Lgf Load resolution - 1/25,000 Load accuracy - ±1% Stroke(exclude the grips) - 450mm Effective width - 130mm Test speed - 2~200mm/min or 25~500mm/min(need to be destined) Speed accuracy - ±1% Stroke resolution - 0.01mm Motor - AC Motor transmission rod - High accuracy ball screw indicator - Indicating marks, grip elongation, test value, max value, displacement, deformation,stop in broken, overload protection Main unit dimension (WxDxH) - 400x450x1180mm Main unit weight - 60kg Power supply - AC220V 5A or specified by user High accuracy Adopt AC servo motor to driving the high precise ball screw working, with high precise explosion-proof load cell, Strength accuracy reached to ±0.25% & displacement accuracy reach to 0.001mm. High performance Automatic breaking identification, automatically return, units are selectable. Multi-function Can coordinate with different grips, the testing of tensile, compression, bending, shearing, tearing, peeling, etc can be done.
