Compression load cell ZA30XS-beamstrain gaugeweighing
Add to favorites
Compare this product
Characteristics
- Type
- compression
- Form
- S-beam
- Technology
- strain gauge
- Applications
- weighing, for hopper
- Other characteristics
- OIML, stainless steel, calibrated, IP68
- Rated load
Max.: 7,500 kg
(8.27 lb)Min.: 500 kg
(1,102.31 lb)
Description
Stainless steel tension load cell
500 kg ... 7.5 t
• S-type Load cell made of stainless steel, IP68 fully welded protection level
• Approved 3 000 d OIML R60 in tension for use in legal for trade weighing applications
• Load cell Dedicated to tension or compression weight measurement
• Ideally used for hoppers weighing, load control on lifting equipment and force measurement in testing applications
• Current calibrated output signal for multi-cell mounting
• Capacities : 0.5, 1, 2, 5, 7.5 t
