Grounding gasket Doubleshield Pad
rectangularsilicone rubberEMI shielding

grounding gasket
grounding gasket
grounding gasket
Add to favorites
Compare this product


silicone rubber
EMI shielding, for printed circuit boards
Other characteristics
grounding, flexible


Introduction Grounding pads, also known as surface mount gaskets or board pads, ensure electrical performance without breaking under mechanical or environmental stress throughout the lifetime of the product. Schlegel’s Doubleshield Pad ensures reliable grounding performance in electronic applications. The Pads are delivered in tape-and-reel packaging for automated placement and soldering reflow using standard SMT equipment. Features and Benefits The flexible and easily compressible grounding pad can to take up tolerances and close the gap between a PCB and another component in addition to providing a reliable grounding contact. SMT compatible Excellent mechanical properties Large conformable contact area Applications The Doubleshield Pad is used as a grounding contact on printed circuit boards commonly used in the electronics industry. Product Description The Doubleshield Pad has hollow profile with a core of soft silicone and a shell of electrically conductive silicone rubber filled with Ni/C particles.
