Product overview
The SenseCAP A1102 LoRaWAN® Vision AI Sensor is an IP66-rated edge device that runs TinyML models locally and transmits only inference results via LoRaWAN (863–928 MHz) to reduce bandwidth and preserve privacy. It captures and processes images at 480×480 resolution at ~10 FPS and ships with pre-deployed models for human detection, people counting and meter reading. The device supports TensorFlow Lite and PyTorch model formats and integrates with SenseCraft for no-code model deployment and training.

Key features

• Edge AI vision: MCU-based vision processor performing on-device inference at 480×480 (~10 FPS), sending compact inference payloads instead of raw images.
• No-code and framework support: Preloaded models for human detection, people counting and meter reading; compatible with TensorFlow Lite/PyTorch and SenseCraft platform for training and deployment.
• LoRaWAN® connectivity: Supports global bands (863–928 MHz), LoRaWAN v1.0.3 Class A, with typical ranges from 2 to 10 km depending on environment.
• Dual power options: Built-in replaceable 19 Ah Li-SOCl2 D-size battery for cyclic operation; optional 12 V DC input via external junction box for continuous power.
• Outdoor-ready enclosure: IP66 protection rating and operating range from 0 °C to 70 °C for outdoor deployments.
• Cloud and management: Integrates with SenseCraft Mate mobile app and web portal for device configuration, data visualization and API access.

Power Supply Options
Option 1: Cyclic operation using the supplied 19 Ah D-size Li-SOCl2 battery (commercially available and replaceable) for long-term standalone outdoor use.
Option 2: Continuous operation via 12 V DC input using an external junction box for wiring and mains or solar-powered installations.

Hardware overview
Onboard components include a vision AI processor (Himax-6538) and a LoRaWAN network MCU (Wio-E5 / STM32WLE5JC). The camera module (OV5647) with a 1/4" sensor and 3.4 mm focal length is mounted in a protective enclosure with mounting points for external installation.

Applications

• Person detection
• People counting
• Face detection
• Specific object or meter reading detection

Specifications

• Product Model: SenseCAP A1102
• Microcontrollers: Vision AI: Himax-6538; LoRaWAN Network: Wio-E5 (STM32WLE5JC)
• Camera: OV5647 module; Lens: 1/4"; Focal length: 3.4 mm (adjustable); Resolution: 2592×1944; Pixel size: 1.4 µm; Max framerate: 1080p@30 FPS, 720p@60 FPS; FOV: 62°
• Model execution: 480×480, >10 FPS
• LoRaWAN®: v1.0.3 Class A; Bands: IN865 / EU868 / US915 / AU915 / AS923; Range: 2–10 km (environment dependent); Max TX power: 19 dBm
• Power supply: Built-in battery or DC 12V/1A (with external junction box)
• Power consumption: 102 mA
• Battery: 19 Ah non-rechargeable D-size Li-SOCl2
• Local storage: 8 GB MicroSD (Class 10), up to ~20,000 timestamped images
• Ingress protection: IP66
• Operating temperature: 0–70 °C
• Operating humidity: 0–100% RH (non-condensing)
• Cable length: 2 m
• Weight: 719 g
• Dimensions: Camera 180×75×70 mm; DTU 144.5×63×57 mm
