Conductivity control unit MCA800

digitalDIN rail

Unit for the measurement of pH, Redox, turbidity, suspended solids, conductivity, dissolved oxygen 2 independent Analytical measurements 2 analog output 4+20mA 5 fully configurable relay 2 open collector digital output Datalogger via Pen Drive USB (optional) Description MCA800 unit suitable for Analytical in wastewater plants. MCA800 can be connected to SGM-LEKTRA digital Analytical sensors for the measurement of pH, Redox, turbidity, suspended solids, conductivity, dissolved oxygen. MCA800 is suitable for direct connection of up to 2 digital Analytical sensors via MODBUS RTU. Additional information Housing material - ABS Mechanical installation - wall, pipe or DIN rail mounting Display - 320×240 matrix color LCD with backlight Electrical connection - Internal connectors Power supply - 85÷265 Vac; 20÷30Vdc Power consumption - Max. 10W Analog output - n.2 4 ÷ 20mA configurable; isolated Relays output - n.5 fully configurable relays (5A 250Vac) Digital outputs - 2 open collectors (max 24Vdc 50mA) Data Logger - on USB Pen Drive; max.32GB (FAT32) Matching sensors - 104C – PH, 114C – Conductivity, 114CH – High Conductivity, 164CH – High Turbidity, 164CL – Low Turbidity, 164CU – Suspended Solids, 324C – Dissolved Oxygen, 604C – Redox
