LED variable-message sign ABC-401

industrial

Overview
Designed for large-scale port equipment, construction machinery and cranes to indicate travel and operational directions. The Arrow Panel Display ABC-401 delivers clear visual directional signaling for operators and site traffic control in industrial outdoor environments.

Features

• Stainless steel enclosure with powder coat finish for corrosion resistance and low maintenance.
• Super-bright LED clusters as the light source for extended service life.
• Transparent safety glass front panel providing high transmittance and a sealed front (IP65).

Application
Suitable for port cranes, spreaders, heavy-duty engineering machinery and other industrial vehicles to signal direction of travel or operation and to enhance on-site safety and coordination.

Technical specifications

• Product name: Arrow Panel Display
• Model: ABC-401
• Light type: LED
• LED color: Red
• LED lifetime: ≥100,000 hrs
• Visible distance: ≥200 m
• Voltage: DC 24V
• Power: 75W
• Operating temperature: -30°C ~ +70°C
• Relative humidity: 10% ~ 95% (no condensing)
• Weight: 35.5 kg
• Material: Stainless steel
• IP rating: IP65
