Semiconductor fuse-link HBD-16EPClass aRDCceramic
Add to favorites
Compare this product
Characteristics
- Class
- Class aR
- Other characteristics
- ceramic, DC, high-voltage
- Applications
- battery, for semiconductors
- Amperage
Max.: 700 A
Min.: 20 A
- VAC
690 V
- VDC
550 V
- Breaking capacity
Max.: 100,000 A
Min.: 20,000 A
Description
Application: Solar Power Systems, Battery Protection, DC Motor Drives, Industrial Power Distribution, Wind Turbine Power Systems, Electric Vehicle (EV) Charging Stations
1. Scope&Application
BS88 semiconductor fuse link is specially apply to all kinds of BDU/PDU branch protection of EV, excellent power of resisting voltaic impingement and environment. Dissmann BS88 series fuse HBD-EP is filling with glue, which have the characteristics of small size, and high reliability. Applicable to a wide temperature range, can withstand high-intensity mechanical vibration and shock, temperature shock and strong chemical load.
2. Basic Informations
* Breaking Capacity: DC20KA AC100KA
* Material of Body
* Mounting Stype: Bolted Connection
* Certificate: UL,CCC,Compliance with EU and China RoHS directives
