Current-limiting fuse MEV-J-G73-800
Class aRDClow power loss

Current-limiting fuse - MEV-J-G73-800 - Shenzhen Deer Electronic Co.,Ltd. - Class aR / DC / low power loss
Current-limiting fuse - MEV-J-G73-800 - Shenzhen Deer Electronic Co.,Ltd. - Class aR / DC / low power loss
Current-limiting fuse - MEV-J-G73-800 - Shenzhen Deer Electronic Co.,Ltd. - Class aR / DC / low power loss - image - 2
Current-limiting fuse - MEV-J-G73-800 - Shenzhen Deer Electronic Co.,Ltd. - Class aR / DC / low power loss - image - 3
Add to favorites
Compare this product

Characteristics

Type
current-limiting
Class
Class aR
Other characteristics
DC, low power loss
Applications
battery
Amperage

Min.: 160 A

Max.: 800 A

VDC

1,000 V

Breaking capacity

50,000 A

Description

Breaking Capacity:DC50kA Installation:Mounting bolt M10 screw Meet the requirement:IEC60269、UL248、Compliance with EU and China RoHS directives Application:short circuit overcurrent and backup protection for energy storage system, power system, wire and other devices and equipment Dissmann Fuse DC1000V 800A MEV series fuse sspecial designed for short circuit overcurrent and backup protection for energy storage system, power system, wire and other devices and equipment,offers wide range current of 160A-800A under DC1000V.This product is a bolt connection type partial range protection fuse, with low I²t, strong current limiting capacity, high breaking capacity and other characteristics, suitable for rail transit, electric vehicles, ships and other industries. Product description of MEV-J-G73 fuse Approvals&Standards IEC60269、UL248 Features&Benefits electrical system available High interrupting rating up to DC50KA Conform to IEC60269、UL248 Low power loss and temperature rise for energy efficiency strong current limiting capacity Applications Power converters/rectifiers AC/Dc commom systems Frequency converters Battery energy storage systems wire and other devices and equipment
