DC fuse Mev100j400-4
cylindricalfast-actingbattery

DC fuse - Mev100j400-4 - Shenzhen Deer Electronic Co.,Ltd. - cylindrical / fast-acting / battery
DC fuse - Mev100j400-4 - Shenzhen Deer Electronic Co.,Ltd. - cylindrical / fast-acting / battery
DC fuse - Mev100j400-4 - Shenzhen Deer Electronic Co.,Ltd. - cylindrical / fast-acting / battery - image - 2
DC fuse - Mev100j400-4 - Shenzhen Deer Electronic Co.,Ltd. - cylindrical / fast-acting / battery - image - 3
DC fuse - Mev100j400-4 - Shenzhen Deer Electronic Co.,Ltd. - cylindrical / fast-acting / battery - image - 4
Add to favorites
Compare this product

Characteristics

Configuration
cylindrical
Type
fast-acting
Other characteristics
DC
Applications
battery
Amperage

Max.: 800 A

Min.: 160 A

VDC

1,000 V

Breaking capacity

30,000 A

Description

Breaking Capacity:DC30kA Installation:Mounting bolt M8/M10/M12 screw Meet the requirement:IEC60269、UL248、Compliance with EU and China RoHS directives Application:EV/HEV、Electrical Energy Storage、Battery pack protection、Battery Disconnect Unit (BDU)、Battery Junction Box for auxiliaries、Battery charger、Supercapacitor pack protection、Backup protection for DC relay、disconnector、switch、Maintenance Safety Disconnect (MSD) Dissmann Fuse make a good fuse for DC Over-Current protection,involved in all realted area of EV charging station,Ev charging module,EV battery pack,Solar PV,5G communication,UK plug,Maintenance safety disconnect(MSD),Battery charger,Electrical energy storage,etc,. Dissmann HEV series fuse equivalent to Mersen m-fuse,the HEV series fuse available line in DC150V(HEV-A-Q)、DC500V(HEV-H-Q)、DC700V(HEV-P-Q)、DC1000V(HEV-J-Q),rated current range from 160-800A,the interrupting caapacity up to DC30KA.
