Network - 3G/4G - Support 3G/4G communication module,
Mini-PCIe interface, pop-up SIM card
Network - LAN1:Intel I210 GbE LAN, RJ45
Super I/O - Watch Dog Timer - 0~255 sec.,providing Watch Dog program.
Front panel - Memory - SODIMM socket
I/O interface - 3.5mm standard headphone jack
3.5mmstandard microphone jack
PB 2PIN 3.5MM phoenix Pin-header, debug interface
Switch - Power switch with LED
Indicator - Hard disk and power supply indicator
GPIO - 12 bit, provide routines, freely define input / output, jumper
can select 3.3V/5V@24mA level, and extend from SMBUS.
Power - 9-30V DC external power input jack
Antenna - WIFI&BT、3G/4G external antenna
I/O interface - Com7 5-wire RS232,supporting 4000V surge protection, DB9 Port
Rear panel - I/O interface - Com1 9-wire RS232,supporting 4000V surge protection, DB9 Port
Power - DC9-30V input,support power reverse and overvoltage protection
Power - Power consumption - Max. 50W
Environment - Operating Temp. - -20°C ~ 60°C
Storage Temp. - -40°C ~ 80°C
Operating Humidity - 0% ~ 90% relative humidity,non-condensing
Storage Humidity - 0% ~ 90% relative humidity,non-condensing
Formfactor - Dimensions - 215x 136x 60mm
Weight - 1.4KG(Net weight)
Certificate - 3C,FCC, CE, RoHS
