Hydrogen gas purifier

nitrogenheliumcompressed air

Overview Impurities in gases (hydrocarbons, moisture and oxygen) can contaminate gas lines and analytical instruments, accelerate column degradation and affect analytical accuracy, potentially causing instrument downtime. Even with high-purity gases, contaminants may originate from regulators or other gas-line components; an additional gas filter is therefore essential.

Introducing the Shimadzu Super-Clean Gas Filter The Shimadzu Super-Clean Gas Filter is engineered to remove hydrocarbons, moisture and oxygen and to deliver an outlet gas of 99.9999% purity. It reduces column degradation, prevents ghost peaks and baseline fluctuations, minimizes detector noise and helps maintain instrument performance.

Ensure High-purity Gas The filter removes hydrocarbons, moisture and oxygen to provide outlet gas purity of 99.9999%. Using contaminant-free gas reduces column wear, prevents anomalous peaks and baseline drift, and lowers detector noise—critical for reliable GC analyses.

Easy and Leak-tight Replacement The filter design enables quick, tool-free cartridge replacement. Spring-loaded check valves seal when a cartridge is removed and open only when a new cartridge is locked in place, preventing contamination of the system during replacement.

Connections Fittings that connect the filter and gas supply pipe are Shimadzu M type, allowing direct, leak-free connection to Shimadzu gas supply pipes for a clean gas line.

Unique Body Design A plastic body facilitates indicator checks and cartridge replacement. To prevent contaminant diffusion and helium leakage, absorbents are packed in glass inside the plastic body.

Easy-to-read Indicator The filter includes a color-change indicator that signals when the absorbent is saturated and cartridges need replacement.

Product Information Super-Clean Gas Filter Kits
P/N | Description
227-37034-02 | Shimadzu Carrier Gas Filter Kit — Includes one 1-position base plate with M type connectors, one Oxygen/Moisture/Hydrocarbon filter
227-37036-01 | Shimadzu Gas Filter Kit for GC-FID/FPD — Includes one 3-position base plate with M type connectors; one Oxygen/Moisture/Hydrocarbon filter for Carrier gas; two Hydrocarbon/Moisture filters for H2 and Air
227-37035-01 | Shimadzu Gas Filter Kit for GC-ECD — Includes one 2-position base plate with M type connectors; one Oxygen/Moisture/Hydrocarbon filter for Carrier gas; one Oxygen/Moisture filter for Nitrogen
227-37036-02 | Shimadzu Gas Filter Kit for compressed air — Includes one 3-position base plate with M type connectors; one Oxygen/Moisture/Hydrocarbon filter for Carrier gas; one Hydrocarbon/Moisture filter for H2; one Hydrocarbon filter for Compressed air
227-37034-01 | Shimadzu Makeup Gas Filter Kit for separate makeup gas — Includes one 1-position base plate with M type connectors; one Hydrocarbon/Moisture filter
227-37034-03 | Shimadzu Carrier Gas Filter Kit (Helium spec) — Includes one 1-position base plate with M type connectors; one Oxygen/Moisture/Hydrocarbon Helium-purged filter

Characteristics / Technical specifications

• Removes hydrocarbons, moisture and oxygen
• Outlet purity: 99.9999%
• Spring-loaded check valves for contamination-free cartridge replacement
• Tool-free, quick cartridge replacement
• Shimadzu M type connectors for leak-free direct connection to Shimadzu gas pipes
• Plastic body with absorbents packed in glass to prevent diffusion and helium leaks
• Color-change indicator to signal saturated absorbent
• Available kit configurations for carrier gas, GC-FID/FPD, GC-ECD, compressed air and makeup gas (product P/Ns listed above)
